# 1 exhaust camshaft
夹具描述：夹具采用端面定位、V型块定角向、两端加紧方式钻攻端面螺纹孔。 Fixture description: Fixture using end positioning, V-shaped block fixed Angle, both ends of the way to drill and tap the end thread hole.
Showing all 12 results
-
-
Back-removable switch lower seat
Product name: Back-removable switch lower seat Clamp description: The clamp uses two claws to clamp and process the red part and end face of the part.
-
Disassembled switch upper seat Clamp
Product name: Back-mounted switch base Clamp description: The clamp uses a spring to expand the outer circle, the side angle is positioned, and the red part of the part is processed on the four axes.
-
Disassembled switch upper seat Clamp uses two claws
Product name: Disassembled switch upper seat Clamp description: The clamp uses two claws to clamp parts and process semicircular
-
-
-
Left and right steering knuckle
夹具描述：夹具采用车床拉杆手动夹紧定位、挡板限角向方式车加工端面。 Fixture description: The fixture uses a lathe pull rod to manually clamp and position, and a baffle to limit the angle of the end face.
-
lower yoke
夹具描述：夹具采用第四轴旋转、端面定位、中心拉缸夹紧方式钻攻外圆螺纹孔及铣槽；端面定位、中心拉缸加紧钻攻端面螺纹孔。 Fixture description: The fixture uses the fourth axis rotation, end face positioning, the center cylinder clamping mode to drill and tap the external round thread hole and milling groove; Face positioning, center cylinder tightening drilling face thread hole.
-
-
ProPump body clamp adopts outer circle
Product name: Pump body Clamp description: The clamp adopts outer circle V-shaped and two-point positioning, and the red part of the processing part is different from the 18 sets in the clamping mechanism.
-
Steering knuckle five-axis hydraulic fixture
